Qualification facts buyers can extract quickly
Offline BLE app cabinet lock for parcel, office, and managed locker fleets. App + PIN + MIFARE card, remote credential management, no server dependency, battery-powered retrofit.
- Who it is for
- Parcel and last-mile locker operators, Office and managed-fleet locker buyers
- Use cases
- Parcel and last-mile locker stations with time-limited pickup, Office shared cabinets with rotating users, Hotel staff and housekeeping cabinets with auditable grants
- MOQ
- 500 pcs for standard models; negotiable for OEM/ODM
- Lead time
- Samples 7-10 days / Mass production 20-30 days
- Certifications
- CE, FCC, RoHS, ISO 9001
- Served markets
- Worldwide (CE/FCC/RoHS certified)
- Export context
- Offline BLE app cabinet lock; remote credential management for managed fleets
- Next step
- Send your fleet size and credential workflow — we will return a BLE SKU plan with the matching app behavior.
Product overview
Why choose a Bluetooth cabinet lock
The Bluetooth Cabinet Lock adds app-based credential management to an offline lock: a mobile app over BLE issues, revokes, and schedules access without a server on the cabinet side. For a parcel fleet or managed office cabinet, that means time-limited pickup codes, auditable grants, and automatic revocation — all with the simplicity of a battery-powered retrofit.
How a Bluetooth cabinet lock works
An operator or end user opens the app and unlocks over BLE; the lock verifies the credential on-chip and drives the latch. PIN and MIFARE card act as fallback so a dead phone battery never blocks access. The app also programs time-limited credentials — a parcel pickup window, a visitor stay, a temporary staff shift — and revokes them automatically when the window closes. The lock keeps working through any network outage because authentication remains local.
Specifications
| Parameter | Value |
|---|---|
| Unlock methods | BLE app + PIN + MIFARE card |
| Bluetooth | BLE 4.2+ |
| Card frequency | 13.56 MHz (MIFARE S50/S70) |
| Read time | < 0.6 s |
| Power | DC 6V (4× AA alkaline) |
| Standby / working current | < 30 µA / < 150 mA |
| Battery life | ~1 year (alkaline, not bundled) |
| Lock body | Zinc alloy |
| Warranty | 14 months |
Applications
- Parcel and last-mile locker stations — time-limited pickup codes issued and revoked from the app.
- Office shared cabinets — rotating users with auditable grants and automatic revocation.
- Hotel staff and housekeeping cabinets — managed access with a clear grant history.
Certifications and export
CE, FCC, and RoHS certified for direct EU and US import; each lock ships with compliance documents. Sampling in 7–10 days, mass production in 20–30 days with FOB Shenzhen, CIF, or DDP logistics. OEM branding, app customization, and firmware support available at MOQ.
Compare BLE against RFID and PIN alternatives in our cabinet lock comparison guide.
Key selling points
Offline BLE app management
Issue, revoke, and schedule credentials from a mobile app over BLE; the lock keeps working with no server or WiFi on the cabinet side.
PIN and card fallback
Three credentials — BLE app, PIN, MIFARE card — so a dead phone battery never locks a user out.
Remote credential lifecycle
Grant time-limited access for parcel pickup, visitor stays, or temporary staff, then revoke automatically.
Battery-powered 5-minute retrofit
Standard mortise and 4× AA power; fits existing cabinets with no rewiring or network cabling.
Technical specifications
| Voltage | DC 6V |
|---|---|
| Standby Current | 30 µA |
| Working Current | 150 mA |
| Unlock Ways | BLE App + + MIFARE |
| Bluetooth | BLE 4.2 |
| Card Frequency | 13.56 MHz |
| Panel Size | L120 × W58 × D16 mm |
| Read Time | 0.6 s |
| Battery Life | 1 year |
| Lock Body | Zinc alloy |
| Mortise | Plastic standard, +$2 metal |
| Warranty | 14 months |
| Working Temp | 0–60 °C |
| Humidity | 15–85 % RH |
