Offline BLE app cabinet lock for parcel, office, and managed locker fleets. App + PIN + MIFARE card, remote credential management, no server dependency, battery-powered retrofit.
The Bluetooth Cabinet Lock adds app-based credential management to an offline lock: a mobile app over BLE issues, revokes, and schedules access without a server on the cabinet side. For a parcel fleet or managed office cabinet, that means time-limited pickup codes, auditable grants, and automatic revocation — all with the simplicity of a battery-powered retrofit.
An operator or end user opens the app and unlocks over BLE; the lock verifies the credential on-chip and drives the latch. PIN and MIFARE card act as fallback so a dead phone battery never blocks access. The app also programs time-limited credentials — a parcel pickup window, a visitor stay, a temporary staff shift — and revokes them automatically when the window closes. The lock keeps working through any network outage because authentication remains local.
| Parameter | Value |
|---|---|
| Unlock methods | BLE app + PIN + MIFARE card |
| Bluetooth | BLE 4.2+ |
| Card frequency | 13.56 MHz (MIFARE S50/S70) |
| Read time | < 0.6 s |
| Power | DC 6V (4× AA alkaline) |
| Standby / working current | < 30 µA / < 150 mA |
| Battery life | ~1 year (alkaline, not bundled) |
| Lock body | Zinc alloy |
| Warranty | 14 months |
CE, FCC, and RoHS certified for direct EU and US import; each lock ships with compliance documents. Sampling in 7–10 days, mass production in 20–30 days with FOB Shenzhen, CIF, or DDP logistics. OEM branding, app customization, and firmware support available at MOQ.
Compare BLE against RFID and PIN alternatives in our cabinet lock comparison guide.
Issue, revoke, and schedule credentials from a mobile app over BLE; the lock keeps working with no server or WiFi on the cabinet side.
Three credentials — BLE app, PIN, MIFARE card — so a dead phone battery never locks a user out.
Grant time-limited access for parcel pickup, visitor stays, or temporary staff, then revoke automatically.
Standard mortise and 4× AA power; fits existing cabinets with no rewiring or network cabling.
| Voltage | DC 6V |
|---|---|
| Standby Current | 30 µA |
| Working Current | 150 mA |
| Unlock Ways | BLE App + + MIFARE |
| Bluetooth | BLE 4.2 |
| Card Frequency | 13.56 MHz |
| Panel Size | L120 × W58 × D16 mm |
| Read Time | 0.6 s |
| Battery Life | 1 year |
| Lock Body | Zinc alloy |
| Mortise | Plastic standard, +$2 metal |
| Warranty | 14 months |
| Working Temp | 0–60 °C |
| Humidity | 15–85 % RH |
